2 Post Hoist – 4.5 Ton – Clear Floor Model
Features
- Dimensions suit shed/ workshop use
- Single phase 240v motor as standard
- No floor plate restrictions
- 4.5 Ton rating will lift heavy vehicles with ease
- Minimum 3.8 metre ceiling height required
- 4500kg/ 4.5 ton safe load limit
- Lifting height of 1.9m (plus screw pad adjustment and raising adapters)
- Dual hydraulic cylinders lift the carriages by direct hydraulic force
- Adjustable screw pads and 4 additional raising adapters are included
- Strong single piece column design
- Durable powder coated finish
- Rubber door protectors
- Symmetric two and three stage arms
- No floor plate restrictions
Australia’s best selling 2 Post Hoist. Designed to fit a wide range of sheds — It’s the perfect choice for commercial
workshops and car enthusiasts that want to get serious about their hobby.
Safety Features
- Manual safety locking system with safety latches in each column
- Single point release system
- Heavy duty 6mm thick columns & carriages
- 10mm steel wire rope equalising cables
- Anti-surge valve in the hydraulic power unit
What’s Included?
- 2 post hoist with all bolts, cables, lines and fixings
- 240V single phase hydraulic power unit
- Concrete anchor bolts
- Detailed installation instructions
What’s Not Included?
- Hydraulic oil
- Setup of power units electrical connection
- Shed Requirements
- 150mm deep concrete at 32mpa
- Minimum ceiling height of 3.8m
Warranty & Certifications
- 3 year Australian warranty* includes structure, hydraulics & electrics
- Australian WorkSafe registered design
- CE certification
